Proteus Professional

Proteus is a software package for computer-aided design of electronic circuits. The package is a system of circuit simulation based on models of electronic components adopted in PSpice. A distinctive feature of the Proteus Professional package is the ability to simulate the operation of programmable devices: microcontrollers, microprocessors, DSP, and more. Additionally, the Proteus package includes a PCB design system. Proteus Professional can simulate the following microcontrollers: 8051, ARM7,AVR,Motorola, PIC, Basic Stamp. The component library contains reference data.

Supports MK: PIC, 8051, AVR, HC11, MSP430, ARM7 / LPC2000 and other common processors. Over 6,000 analog and digital device models. Works with most compiler and assembler.PROTEUS VSM allows you to very reliably simulate and debug quite complex devices that can contain several MKs simultaneously and even different families in one device! Add. Information : Installation instructions in readme.txt Performance tested in wine-3.0.3 on Debian 9 with 32-bit WINEPREFIX. It works more stably than 8.8 (there were problems with saving projects).

For academics and the maker market, Proteus Visual Designer allows Arduino programs to be written with simple flowcharting methods and Arduino shields to be placed on the schematic with a mouse click. The entire Arduino system can then be simulated, tested and debugged in software. Proteus IoT builder then adds the ability to create a user interface for your phone or tablet to interact with the Arduino electronics. You can even test this by controlling the running simulation from your mobile device.

Details:

• Proteus Design Suite 8.9 SP2 Release
• Version:8.9 SP2 Build 28501
• Developer:Labcenter Electronics
• Tabletka:present.

Features of Proteus 8:

• Proteus PCB design seamlessly combines Schematic Capture and PCB layout to provide a powerful, integrated and easy to use suite of tools for professional PCB Design.
• Visual Designer for Arduino combines world class Proteus VSM simulation with a new flowchart engine to provide a truly integrated and intuitive development environment.
• The Proteus Design Suite is wholly unique in offering the ability to co-simulate both high and low-level micro-controller code in the context of a mixed-mode SPICE circuit simulation.

System Requirements:

• Supported OS: Windows 7/8/10
• CPU: 2.2GHz Dual Core
• RAM: 4 GB RAM
• Free Hard Disk Space: 1 GB or more.
